Part Number:
90MB1IQ0-M0EAY0

Chipset:
Z890

Memória:
4x DIMM slots, max. 256GB, DDR5
Support up to 9066+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
Dual channel memory architecture
DIMM Fit
Supports Intel® Extreme Memory Profile (XMP) memory module
ASUS Enhanced Memory Profile III(AEMPIII)

Processador:
Intel LGA 1851 ( Intel 15ª Geração )
Intel® Core™ Ultra Processors (Series 2)

Slots:
Intel® Core™ Ultra Processors(Series 2)*
1x PCIe 5.0 x16 slot
Intel® Z890 Chipset
1x PCIe 4.0 x16 slot (supports x4 mode)
1x PCIe 4.0 x4 slot
2x PCIe 4.0 x1 slots

Armazenamento:
Total Supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*
Intel® Core™ Ultra Processors(Series 2)*
M.2_1 slot (Key M), type 2242/2260/2280  (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
Intel® Z890 Chipset
M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
4 x SATA 6Gb/s ports
* Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only support RAID 0/1/5.

Rede:
1x Intel® 2.5Gb Ethernet
TUF LANGuard
Wi-Fi 7
2×2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band
Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
Bluetooth® v5.4

Áudio:
Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC*
Impedance sense for front and rear headphone outputs
Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
Supports up to 32-Bit/192 kHz playback

Input / Output:
1x Thunderbolt™ 4 USB Type-C® port
1x USB 20Gbps port (1 x USB Type-C® with DP Alt mode)
3x USB 10Gbps ports (3 x Type-A)
3x USB 5Gbps ports (3 x Type-A)
1x DisplayPort
1x HDMI™ port
1x Wi-Fi module
1x Intel® 2.5Gb Ethernet port
5x Audio jacks
1x Optical S/PDIF out port
1x BIOS FlashBack™ button

Dimensões:
ATX ( 30.5 cm x 24.4 cm )
