Part Number:
911-7E42-002

Chipset:
B860

Memória:
4x DDR5 UDIMM, Maximum Memory Capacity 256GB
Memory Support 7200 – 6400 (OC) MT/s / 6400 – 4800 (JEDEC) MT/s

Processador:
Intel LGA 1851 ( Intel 15ª Geração )
Intel® Core™ Ultra Processors (Series 2)

Slots:
2x PCI-E x16 slot
Supports x16/x4 (For Ryzen™ 9000/ 7000 Series processors)
Supports x8/x4 (For Ryzen™ 8700/ 8600/ 8400 Series processors)
Supports x4/x4 (For Ryzen™ 8500/ 8300 Series processors)
1x PCI-E x1 slot
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)

Armazenamento:
2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
4x SATA 6G

Rede:
1x Realtek® 8125BG 2.5G LAN

Áudio:
Realtek® ALC897 Codec
7.1-Channel High Definition Audio

Input / Output:
4x USB 3.2 Gen 2 10Gbps (Type-A)
4x USB 3.2 Gen 1 5Gbps (Type-A)
1x 2.5G LAN ( RJ45 )
2x Wi-Fi / Bluetooth
3x Audio connectors
1x Flash BIOS Button
1x DisplayPort
1x HDMI™

Dimensões:
mATX ( 243.84 mm x 243.84 mm )
